Ni pxi chassis slot symbols
The National Instruments PXIe slot chassis, designed for a wide range of test and measurement applications, provides a high-bandwidth backplane with up to 1 GB/s per-slot dedicated bandwidth to meet high-performance needs. The NI PXIe offers a solution for high-channel-density PXI Express. NI PXI slot blockers enhance system cooling by redirecting airflow from unused PXI slots to populated slots. While they are not required to ensure proper PXI system operation, slot blockers in unused slots provide enhanced PXI system cooling. Reducing the operating temperature improves long-term. The PXIe module only fits in slot 1 of a PXIe chassis. For more information on what slots a PXI or PXIe module can fit in, please see Meaning of PXI and PXIe Slot Symbols. was this article helpful?
PXI/PXI Express Chassis Recommendations
Any idea what went wrong here? I just wanted to be thorough about what may have happened in this situation to cause this thermal event. We are committed to making our documentation as clear and as thorough as possible, so if any documentation concerning this is unclear, we are concerned with how we can improve the documentation to account for this. Message 1 of 6. I'm not sure what I did wrong, and now I'm worried that I might have damaged some of the other cards that were installed in the chassis.
I followed the instructions that came with the card, but after powering on the chassis, there was no hardware detection wizard, and no LED light came on.
I was going to try it in a different slot, but when I slid the card out of the chassis, I saw that the socket looked burned see image attached. I'm not sure what I did wrong, and now I'm worried that I might have damaged some of the other cards that were installed in the chassis. So my question is two-fold: Any idea what went wrong here? Any way to tell if the chassis itself is somehow damaged? Everything seems to be working ok now, thank zeus.
Can you walk me through exactly how you inserted the card? Did you insert the card before turning on the chassis? If you are pretty confident that you followed the instructions correctly, then there was probably some sort of damage either on the chassis or the card.
Can you provide a screenshot of the backplane of the chassis as well? Maybe look for some bent pins in the chassis that may have caused a short? Can you use a multimeter to check the voltage on the pin from the PXI chassis where it seemed like the card was melted? It's possible that there was a short either in the card itself or the chassis. Whether or not you are under warranty is probably going to depend on when you bought your hardware. I would call in to NI to get more information about that.
